Solidstate Amplifier

Company Image Placeholder

Product Overview

Solid State Amplifiers (SSAs) are high-performance RF amplifiers designed for applications requiring reliability, efficiency, and compact form factors. Using advanced GaN, LDMOS, and GaAs device technologies, these amplifiers deliver high output power across a wide frequency range from C to V-Band, supporting radar, SATCOM, and data-link systems. With their small size, lightweight construction, and cost-effective design, they offer a versatile solution for both standard and custom configurations.

Key Features

  • High Reliability and high efficiency
  • Various Frequency Range to C,X,Ku,Ka,V Band
  • High output power(for Rader/SATCOM/Datalink)
  • GaN, LDMOS and GaAs device technologies
  • Small Size & Light Weight
  • Cost-Effective Solution
  • Several Standard Options available as well as Custom Design

Applications

  • Satellite Communication
  • Military and Commercial Radar systems
  • Electronic warfare systems
  • Tatical Communication system
  • Test and measurement
0 selected
Part Number Frequency (MHz) Pout (Watts) Gain (dB) Voltage (Volts) Current (Amps) Size (mm)
EHP30-88P20DC1 30~88 20 43 50 2.5 200 X 100 X 30
EHP88-108P10EJ1 88~108 10 50 27 3.5 162 X 73 X 29
EHP134-176P10EJ1 134~176 10 50 27 3.5 160 X 90 X 25
EHP174-240P10EJ1 174~240 10 50 27 3.5 160 X 90 X 25
EHP300-330P20DE1 300~330 20 45 28 3 230 X 70 X 30
EHP300-450P60EE1 300~450 60 55 28 10 280 X 250 X 45
EHP390-460P2CJ1 390~460 2 30 27 2 140 X 120 X 25
EHP412-414P3DJ1 412~414 3 40 27 2 140 X 120 X 25
EHP450-470P40DC1 450~470 40 43 28 6 80 X 95 X 25
EHP450-600P40EJ1 450~600 40 50 28 8 280 X 250 X 45
EHP700-800P30EJ1 700~800 30 50 27 8 180 X 150 X 28
EHP728-768P60EJ1 728~768 60 50 28 8 230 X 255 X 40
EHP740-806P6EJ1 740~806 6 50 27 5 180 X 150 X 28
EHP791-821P6DE1 791~821 6 45 28 2.5 180 X 150 X 28
EHP800-900P6DE1 800~900 6 45 27 1.6 180 X 150 X 28
EHP806-821P2EB1 806~821 2 52 27 1.5 170 X 110 X 28
EHP824-849P2DJ1 824~849 2 40 28 2.5 170 X 110 X 28
EHP851-894P30EJ1 851~894 30 50 27 11 100 X 90 X 25
EHP869-894P10DE1 869~894 10 45 27 3 135 X 100 X 25
EHP920-960P70DG1 920~960 70 47 28 6.5 135 X 100 X 25
EHP920-960P100DG1 920~960 100 47 27 12 200 X160 X 25
EHP960-1240P200EE1 960~1240 200 55 28 16 200 X160 X 25
EHP1100-1300P200EJ1 1100~1300 200 50 28 20 235 X 180 X 27
EHP1190-1210P20EJ1 1190~1210 20 50 27 8 100 X 90 X 25
EHP1200-1300P100EC1 1200~1300 100 53 28 10 180 X 150 X 28
EHP1490-1510P20EJ1 1490~1510 20 50 27 8 100 X 90 X 25
EHP1500-1700P200EH1 1500~1700 200 56 28 24 235 X 180 X 27
EHP1700-1900P6DJ1 1700~1900 6 40 27 5 100 X 90 X 25
EHP1800-1900P6DE1 1800~1900 6 45 27 5 100 X 90 X 25
EHP1805-1880P25DJ1 1805~1880 25 40 27 3 100 X 90 X 25
EHP1805-1910P25DG1 1805~1910 25 47 27 3 120 X 100 X 25
EHP1900-2000P60EE1 1900~2000 60 55 27 10 180 X 150 X 28
EHP1900-2200P15CH1 1900~2200 15 38 27 3 80 X 95 X 25
EHP1920-1960P8DE1 1920~1960 8 45 27 5 80 X 95 X 25
EHP1930-1990P100DE1 1930~1990 100 45 27 11 180 X 150 X 28
EHP2000-2200P60DG1 2000~2200 60 47 28 6.5 135 X 100 X 25
EHP2100-2200P25DJ1 2100~2200 25 40 27 3 100 X 90 X 25
EHP2110-2170P25DE1 2110~2170 25 45 28 3 100 X 90 X 25
EHP2110-2170P100DE1 2110~2170 100 45 27 12 180 X 150 X 28
EHP2200-2300P25DE1 2200~2300 25 45 28 4.5 100 X 90 X 25
EHP2300-2400P5DE1 2300~2400 5 45 12 2.5 80 X 95 X 25
EHP2300-2620P200EE1 2300~2620 200 55 28 27 280 X 250 X 45
EHP2400-2500P50DE1 2400~2500 50 45 28 6 100 X 90 X 25
EHP2400-2700P25DE1 2400~2700 25 45 28 3 120 X 100 X 25
EHP2500-2700P30DE1 2500~2700 30 45 27 8 180 X 150 X 28
EHP2570-2690P25DE1 2570~2690 25 45 27 12 120 X 100 X 25
EHP2600-2700P10DE1 2600~2700 10 45 27 3 120 X 100 X 25
EHP2620-2690P25CG1 2620~2690 25 37 28 2.5 120 X 100 X 25
EHP2620-2695P100EJ1 2620~2695 100 50 38 13 180 X 150 X 28
EHP3300-3400P10DE1 3300~3400 10 45 27 3 180 X 150 X 28
EHP3400-3600P15DH1 3400~3600 15 46 28 4 200 X 150 X 38
EHP3510-3594P100EJ1 3510~3594 100 50 28 14 200 X 150 X 38
EHP4400-5000P20DH1 4400~5000 20 46 28 2.5 180 X 150 X 28
EHP5070-5270P10CJ1 5070~5270 10 30 28 3 180 X 150 X 28
EHP5700-5900P15DG1 5700~5900 15 47 28 2.5 180 X 150 X 28
